Triaxial Biaxial Plastic Grid Polyester Fiberglass Geogrid for Retaining Wall

Our factory produces durable Triaxial Biaxial Plastic Grid Polyester Fiberglass Geogrid for superior retaining wall construction. Learn more!
Request a Quote

PRODUCTS DETAILS

Basic Info.

Model NO.
geogrid
Material
Polyester
Size
Customizable
Property
Building Material
Width
Customizable
Length
Customizable
Transport Package
Exporting Special Packing
Specification
Customizable
Trademark
Tianren
Origin
China
HS Code
3926909090
Production Capacity
50000 Square Meters/ Day

Product Description


Triaxial Biaxial Plastic Grid Polyester Fiberglass Geogrid for Retaining Wall

1.Product Description:




Geogrid for Reinforcing Soils and Construction Applications



Shandong Tianren New Materials Co., Ltd. offers a wide range of geogrid products designed to reinforce soils and other materials in various construction applications. Our geogrids are the perfect solution for projects such as retaining walls, foundation soil stabilization, and pavement construction.



Key Features:



  • Biaxial and uniaxial geogrid options

  • Raw materials include plastic (PP/HDPE), polyester, fiberglass, steel-plastic, and laminate with non-woven geotextile



  •
  •
Triaxial Biaxial Plastic Grid Polyester Fiberglass Geogrid for Retaining Wall
Triaxial Biaxial Plastic Grid Polyester Fiberglass Geogrid for Retaining Wall
Triaxial Biaxial Plastic Grid Polyester Fiberglass Geogrid for Retaining Wall


Benefits:



  • Enhances soil stability and prevents erosion

  • Improves load-bearing capacity of construction materials

  • Reduces the risk of cracks and settlement in retaining walls

  • Increases the lifespan and durability of pavements

  • Easy to install and cost-effective

  •


Choose Shandong Tianren New Materials Co., Ltd. for high-quality geogrid products that meet your construction needs. Our geogrids are designed to provide superior reinforcement and long-lasting performance. Contact us today to learn more!







Shandong Tianren New Materials Co., Ltd. offers Bi-directional Plastic Geogrid for Ground Reinforcement. Our geogrids are made of virgin plastic polypropylene PP and provide permanent bearing foundation reinforcement for various applications including roadbeds, slope protection, cave walls, airport parking lots, wharf yards, and more. Get factory price geogrids for effective ground reinforcement.

 Projects:
Triaxial Biaxial Plastic Grid Polyester Fiberglass Geogrid for Retaining Wall
Triaxial Biaxial Plastic Grid Polyester Fiberglass Geogrid for Retaining Wall
Triaxial Biaxial Plastic Grid Polyester Fiberglass Geogrid for Retaining Wall

Features:




Product Description




Product Description



Shandong Tianren New Materials Co., Ltd. is proud to present our innovative product that offers numerous benefits for road construction and maintenance.



Key Features:



  • Increased bearing capacity of roadbed and foundation, ensuring a longer service life.

  • Prevention of road surface sinking or flawing, resulting in a clean and beautiful ground surface.

  • Convenient construction that saves time and labor, reducing mounting time and decreasing maintenance expenses.

  • Prevention of culverts from flawing, ensuring their durability.

  • Enhancement of earth slope stability, preventing water loss and soil erosion.

  • Decreased underlayer thickness, resulting in cost savings during manufacturing.

  • Improved stability of side slope turf net patch, enhancing greening efforts.

  • Replacement of wire netting used in mines as intermediate ceiling netting, offering a more efficient solution.

  •


Our product is designed to meet the needs of road construction projects, providing a reliable and cost-effective solution. With its exceptional features, it is the ideal choice for enhancing road durability, preventing flaws, and improving overall stability.





Triaxial Biaxial Plastic Grid Polyester Fiberglass Geogrid for Retaining Wall
Triaxial Biaxial Plastic Grid Polyester Fiberglass Geogrid for Retaining Wall
Triaxial Biaxial Plastic Grid Polyester Fiberglass Geogrid for Retaining Wall

Application:




The geogrid is mainly used for:
1. improve roadbed bearing capacity and prolong roadbed life;
2. prevent road collapse and crack, keeping the ground neat;
3. reinforce soil slope and prevent soil erosion;
4. support slope planting mat for landscaping;
5. replace metal mesh used in coal mine.







Triaxial Biaxial Plastic Grid Polyester Fiberglass Geogrid for Retaining Wall
Triaxial Biaxial Plastic Grid Polyester Fiberglass Geogrid for Retaining Wall
Triaxial Biaxial Plastic Grid Polyester Fiberglass Geogrid for Retaining Wall


Geogrids focus almost entirely on reinforcement applications, although separation may be a function.  The following are examples of a few applications.
Slope Reinforcement- embankments over soft soils, extra-steep earthwork slopes, landfill liner systems, and industrial and contaminated land reclamation
Base Reinforcement- foundations of roadbeds, parking lots, railroad tracks beds, airports runways, permanent unpaved roads, construction haul roads
Wall Reinforcement- retaining walls, sea walls, airport noise barriers, and bridge supports
Berm Reinforcement - spillway channels for earthen dams, levees, and waste contaminated ponds, banks for earthen canals and waterways.










 PP Plastics Geogrid TDS:



Discover our high-quality bi-directional plastic geogrid for ground reinforcement. Made from virgin plastic polypropylene, our geogrids offer excellent durability and strength. Perfect for roadbed reinforcement, slope protection, cave wall reinforcement, airport parking lots, wharf yards, and more. Get factory prices and permanent bearing foundation reinforcement. Shop now!



Specification



TGSG15-15

TGSG20-20

TGSG30-30

TGSG40-40

index

unit

MD CD

MD CD

MD CD

MD CD

True initial modulus in use

KN/m

15 15

20 20

30 30

40 40

true tensile strength @2% strain

KN/m

5  5

7  7

11 11

16 16

true tensile strength @5% strain

KN/m

7  7

14 14

21 21

32 32

junction efficiency

%

100

100

100

100

flexural stiffness

mg-cm

280,000

780,000

900,000

1,200,000

aperture stability

kg-cm/deg

3.1

4.8

4.3

3.4

resistance to installation damage

%SC/%SW/%GP

95/93/90

95/93/90

95/93/90

95/93/90

resistance to long term degradation

%

100

100

100

100

unit weight

g/m2

250-310

270-330

340-420

430-530

rolls dimensions (length, width)

m

50*3.9

50*3.9(5)

50*3.9

50*3.9

loading capacity

rolls/40HC

205

180

120

88




4.Production And Transportation:

Triaxial Biaxial Plastic Grid Polyester Fiberglass Geogrid for Retaining Wall


Geosynthetics Products

Shandong Tianren New Materials Co., Ltd. is a leading professional geosynthetics manufacturer, offering a wide range of high-quality products to international markets. Our extensive product line includes:


  • Geomembrane

  • Geotextile

  • Geocomposites

  • Geogrid

  • Geonet

  • Geocell

  • Geotube

  • Fiber

  •

With years of experience in the industry, we have become a trusted supplier for all geosynthetics requirements. Our products are known for their wide range, exceptional quality, and competitive prices. We ensure full compliance with market reference standards by maintaining strict control over production processes and carefully selecting raw materials.

Choose Shandong Tianren New Materials Co., Ltd. for reliable geosynthetics solutions that meet your needs.




Shandong Tianren New Materials Co., Ltd.

We have extensive experience in various projects such as mining, prawn/fish pond construction, road construction, evaporation ponds, and landfill projects. As a manufacturer, we offer a one-stop solution for our customers, providing a comprehensive range of products and services. When you request more details, we can offer you a complete overview of our capabilities.



Our years of experience have allowed us to develop a wide range of high-quality and competitive products. We pay close attention to every step of the production process and carefully select raw materials to ensure that our products meet the highest market standards.

Triaxial Biaxial Plastic Grid Polyester Fiberglass Geogrid for Retaining Wall

Company Qualification:

Triaxial Biaxial Plastic Grid Polyester Fiberglass Geogrid for Retaining Wall Triaxial Biaxial Plastic Grid Polyester Fiberglass Geogrid for Retaining Wall

Shandong Tianren New Materials Co., Ltd. specializes in the production of bi-directional plastic geogrids for ground reinforcement. Our geogrids, made from virgin plastic polypropylene, are ideal for construction projects such as roadbed reinforcement, slope protection, cave wall reinforcement, airport parking lots, wharf yards, and permanent bearing foundation reinforcement. With our factory price geogrids, you can ensure the strength and durability of your project. Choose our plastic geogrids for reliable ground reinforcement.



Triaxial Biaxial Plastic Grid Polyester Fiberglass Geogrid for Retaining Wall Q : Are you a manufacturer or trading company?
A : We are a professional manufacturer that specialized in geosynthetics with ISO9001 certificate more than 15 years.
Q : How about the delivery time?
A : General within 3-7 days
per 40HQ after received the money
Q : Could you send the sample before order confirmation?
A : Yes, we'd love to send  free sample to you for an evaluation if you need.
Q
:
How do you ensure the quality for large quantity?
A :We are working with four QC processes to guarantee the quality: 1 .For raw materials; 2. Onsite inspection during production; 3.Final QC test for each batch of finished products
Q : Can you produce the product according to customers' requirements?
A : Sure, Our goal is to satisfy customers' requirements to the best. OEM and ODM are both welcome.
