Product Description
500±15 Kg/M³ 1.5-6mm Thermal Insulation Material Ceramic Fiber Gasket Ceramic Fiber Cloth:
Density: 500±15 kg/m³
Raw materials: Ceramic Fiber Bulk
Thickness: 1.5-6mm
Asbestos: 100% Non Asbestos
Function: Insulation,Sealing and filling
Ceramic fiber textile includes ceramic fiber cloth, strap, twisted rope, round braided rope and square braided rope. All are made from our high quality ceramic fiber material. They can be used for high temperature applications up to 2300°F. The rope is reinforced with fiberglass filament, and optional Inconel/alloy steel wire. Ceramic fiber textiles (cloth, tape and rope) contain a certain amount of binder material which is normally burned at lower temperature and does not affect the insulation property.
ROSEWOOL ceramic fiber cloth with wire is a kind of ceramic fiber textile, which is made of ceramic fiber yarn and reinforced by glass fiber or stainless steel. Ceramic fiber cloth owns advantages of low thermal conductivity, excellent high temperature strength.
ROSEWOOL ceramic fiber rope is a woven fabric made from high quality ceramic fiber woven yarn .Ceramic Fiber Rope can can add glass fiber and stainless steel wire reinforcement according to different work temperature and work conditions.
Features of 500±15 Kg/M³ 1.5-6mm Thermal Insulation Material Ceramic Fiber Gasket Ceramic Fiber Cloth:
1. Good compression strength
2. Non-toxicity, environmental protection
3. Low thermal conductivity and low thermal capacity
4. Good antacid oil resistance and water vapor resistance
Application of 500±15 Kg/M³ 1.5-6mm Thermal Insulation Material Ceramic Fiber Gasket Ceramic Fiber Cloth:
Common applications: door seals or caulking for ovens, furnaces and boilers, expansion joints, cable or pipe wrapping, high temperature seals or gaskets. widely used in welding, foundry works, aluminum and steel mills, boiler insulation and seal, exhaust systems, shipyards, refineries, power plants and chemical plants.
Technical Data of 500±15 Kg/M³ 1.5-6mm Thermal Insulation Material Ceramic Fiber Gasket Ceramic Fiber Cloth:
Ceramic Fiber Cloth:
| Temperature(°C) | 1260 | |
| Product Name | Glass-fiber Reinforced Ceramic Fiber Cloth with wire | Stainless-steel Reinforced Ceramic Fiber Cloth with wire |
| Basic Material | Ceramic Fiber/Glass fiber Reinforcement | Ceramic Fiber/Staineless-steel Reinforcement |
| Density(kg/m3) | 500 | |
| Long-term Operation Temp(°C) | 650 | 1050 |
| Water Content(%) | ≤2 | |
| Organic Content(%) | ≤15 | |
| Heat Conductivity(W/m° K) | 500ºC: 0.101 | |
| 650ºC: 0.105 | ||
| 1000ºC: 0.176 | ||
| Packing | Woven Bag | |
| Thickness | 1.5-6mm | |
| Width | 300-1500mm | |
| Length | 10-30m | |
| Diameter of Fiber | 3-5um | |
Ceramic Fiber Rope:
| Classification temperature | 1260°C | |||
| Product | round braided rope | square braided rope | ||
| Basic material | Ceramic fiber | Ceramic fiber | Ceramic fiber | Ceramic fiber |
| Fiberglass reinforced | stainless steel reinforced | fiberglass reinforced | stainless steel reinforced | |
| Theoretical density(kg/m3) | 500~650 | 500~650 | 500~650 | 500~650 |
| Specification(mm) | 50000/10000*25/50 | 10000*(50*50) | ||
| Moisture content(%) | ≤2 | |||
| Delivery state | In Roll | |||
| Organic content(%) | ≤15 | |||
Packing & Shipping:
Certificate:
Rosewool Insulation Refractory Co.,Ltd. was founded in 1960s and located in Zhengzhou, Henan Province, China. It is a comprehensive company, integrating manufacture, sales and construction into one. And we are the largest private enterprises in the field of ceramic fiber material, one of the earliest companies which researched and developed calcium silicate products, and the largest thermal and insulation material company in Henan Province.
1. 1 national R&D institution: Peking University has close relations of cooperation laboratory in product development and
technology with us
2. 4 kinds : Our product range: ceramic fiber products (blanket, paper, board, module,also special shape), rock wool , glass wool
, calcium silicate board.
3. 5 certificates: ISO900, CE, SGS, TUV, BV, etc.
4. 23 years : Our export experience more than 23 years.
5. 150,000 m2 : Our factory total areas.
Our value: To the quality strives for the survival, Energy saving cause parallel.
Our Workshop:
FAQ:
1. Are you a trader or manufacturer?
We are manufacturer, we have own factory.
2. Can you accept OEM or ODM?
Of course, Logo is also acceptable.
3. What is the delivery time?
About 10-20 days after the contract signing.
4. What is your payment methods?
T/T L/C D/P Paypal West Union and others .
5. Do you have warehouses abroad ?
Yes, we have , both in Europe and Middle East. Others is planing.
Any questions, or any needs, please contact us below to get detailed info and best price, thanks for your inquiry:
