Basic Info.
Model NO.
Woven Roving Combo mat
HS Code
3907910000
Production Capacity
50000ton/Year
Product Description
Changzhou Tianma Group Co.,Ltd is one of the earliest research and production base for composite materials in China.Our produt series and capacity as below:
| Products | Yearly capacity |
| Fiberglass roving | 30,000mt |
| Fiberglass fabric and mat | 5,000mt |
| Unsaturated polyester resin | 20,000mt |
| FRP products | 2,000mt |
| Vinyl ester resin | 2,00mt |
| Adhesive | 2.000mt |
| Sheet molding compound | 2,000mt |
| Fiberglass wall covering | 3000,000sqm |
VINYL ESTER RESIN
| Vinyl Ester Resin | |||||||||
| Code | Type | Viscosity | Gel Time | Solid Content | Tensile Strength | Elongation | Bending Strength | HDT | Application |
| TM-V222 | Bisphenol A | 0.3-0.6 | 5-30 | 55-61 | 80 | 5 | 110 | 120 | Standard bisphenol A, corrosion-resistant resin |
| TM-V202 | Bisphenol A | 0.3-0.6 | 5-30 | 57-63 | 70 | 5 | 110 | 120 | General hand lay-up resin |
| TM-V232 | Bisphenol A | 0.15-0.35 | 5-30 | 50-56 | 73 | 5 | 115 | 105 | Low shrinkage, corrosion-resistant resin |
| TM-V301 | Phenolic | 0.2-0.45 | 5-30 | 50-60 | 80 | 3.5 | 120 | 135 | High temperature resin |
| TM-V280 | Molding | 0.25-0.55 | 5-30 | 59-65 | 70 | 3.5 | 100 | 90 | Mold resin |
| TM-V241 | Vaccumm | 0.14-0.2 | 30-120 | 63-67 | 80 | 5 | 130 | 110 | Vacuum resin |
| TM-V512 | flame retardant | 0.35-0.55 | 5-30 | 50-60 | 110 | 3.5 | 150 | Oxygen index 48% | Low smoke flame retardant resin |
