Basic Info.
Model NO.
32313
Spherical
Non-Aligning Bearings
Load Direction
Axial Bearing
Separated
Separated
Outer Dimension
35-400mm
Transport Package
Carton Pallet
Specification
65*140*51mm
Trademark
RTB
Origin
China
HS Code
8482200000
Production Capacity
100000 Pieces/Year
Product Description
![Magnetic/Excavator Needle/Yanmar Main/Car Water Pump/Split/Plastic Thrust Bearings/Hub Bearing for Wuling/Motorcycle Parts/Bearing Housing/Plastic Pulley 32313](http://img6.grofrom.com/www.gaiximachineshop.com/226f3j00rdBPgLIWbJzu/Magnetic-Excavator-Needle-Yanmar-Main-Car-Water-Pump-Split-Plastic-Thrust-Bearings-Hub-Bearing-for-Wuling-Motorcycle-Parts-Bearing-Housing-Plastic-Pulley-32313.webp)
Model | Size | Rated dynamic load (KN) | Rated static load (KN) | Weight (kg) | ||
(mm) | ||||||
d | D | T | ||||
32007 | 35 | 62 | 18 | 43.2 | 59.2 | 0.224 |
32008 | 40 | 68 | 19 | 51.9 | 71.1 | 0.268 |
32009 | 45 | 75 | 20 | 58.4 | 81.4 | 0.339 |
32010 | 50 | 80 | 20 | 61.1 | 89 | 0.367 |
32011 | 55 | 90 | 23 | 80.2 | 117.2 | 0.564 |
32012 | 60 | 95 | 23 | 81.7 | 122.2 | 0.597 |
32013 | 65 | 100 | 23 | 82.8 | 127.3 | 0.628 |
32014 | 70 | 110 | 25 | 104.3 | 160.1 | 0.838 |
32015 | 75 | 115 | 25 | 103.1 | 160.2 | 0.875 |
32016 | 80 | 125 | 29 | 141 | 220 | 1.27 |
32017 | 85 | 130 | 29 | 139.8 | 220.3 | 1.33 |
32018 | 90 | 140 | 32 | 171.3 | 271 | 1.77 |
32019 | 95 | 145 | 32 | 174.6 | 281.3 | 1.796 |
32020 | 100 | 150 | 32 | 173.1 | 281.7 | 1.91 |
32021 | 105 | 160 | 35 | 205. 4 | 335.8 | 2.4 |
32022 | 110 | 170 | 38 | 245.7 | 403.4 | 3.02 |
32024 | 120 | 180 | 38 | 242.1 | 404.4 | 3.18 |
32026 | 130 | 200 | 45 | 333.7 | 567.1 | 4.94 |
32028 | 140 | 210 | 45 | 329.8 | 567.8 | 5.15 |
32030 | 150 | 225 | 48 | 367.6 | 635.8 | 6.25 |
32032 | 160 | 240 | 51 | 419.6 | 734.5 | 7.66 |
32207 | 35 | 72 | 24.25 | 70.6 | 89.5 | 0.426 |
32208 | 40 | 80 | 24.75 | 77.9 | 97.2 | 0.529 |
32209 | 45 | 85 | 24.75 | 80.7 | 104 | 0.587 |
32210 | 50 | 90 | 24.75 | 82.8 | 107.6 | 0.654 |
32211 | 55 | 100 | 26.75 | 108 | 142.3 | 0.881 |
32212 | 60 | 110 | 29.75 | 132.8 | 179.6 | 1.17 |
32213 | 65 | 120 | 32.75 | 160.9 | 221.7 | 1.58 |
32214 | 70 | 125 | 33.25 | 168.5 | 237.1 | 1.66 |
32215 | 75 | 130 | 33.25 | 170.3 | 242.1 | 1.76 |
32216 | 80 | 140 | 35.25 | 198.1 | 279 | 2.19 |
32217 | 85 | 150 | 38.5 | 226.7 | 324 | 2.7 |
32218 | 90 | 160 | 42.5 | 269.8 | 395.5 | 3.61 |
32219 | 95 | 170 | 45.5 | 302.5 | 448.4 | 4.34 |
32220 | 100 | 180 | 49 | 341 | 512 | 5.31 |
32221 | 105 | 190 | 53 | 342 | 517 | 6.37 |
32222 | 110 | 200 | 56 | 388 | 590 | 7.45 |
32224 | 120 | 215 | 61.5 | 420 | 610 | 9.04 |
32226 | 130 | 230 | 67.75 | 551.7 | 888.7 | 11.377 |
32228 | 140 | 250 | 71.75 | 643.7 | 1049.3 | 14.413 |
32307 | 35 | 80 | 32.75 | 99 | 118.3 | 0.766 |
32308 | 40 | 90 | 35.25 | 115.7 | 147.8 | 1 |
32309 | 45 | 100 | 38.25 | 145.3 | 189.4 | 1.41 |
32310 | 50 | 110 | 42.25 | 177.5 | 236.1 | 1.9 |
32311 | 55 | 120 | 45.5 | 203.1 | 271.4 | 2.33 |
32312 | 60 | 130 | 48.5 | 226.7 | 303 | 2.96 |
32313 | 65 | 140 | 51 | 259.6 | 349.8 | 3.53 |
32314 | 70 | 150 | 54 | 298.9 | 408.5 | 4.41 |
32315 | 75 | 160 | 58 | 347.4 | 483.1 | 5.27 |
32316 | 80 | 170 | 61.5 | 387.9 | 543.1 | 6.43 |
32317 | 85 | 180 | 63.5 | 421.8 | 592.8 | 7.31 |
32318 | 90 | 190 | 67.5 | 478.2 | 693.3 | 8.81 |
32319 | 95 | 200 | 71.5 | 516.1 | 737.7 | 10.1 |
32320 | 100 | 215 | 77.5 | 600.1 | 872.2 | 13 |
30207 | 35 | 72 | 18.25 | 54.2 | 63.5 | 0.333 |
30208 | 40 | 80 | 19.75 | 63 | 74 | 0.431 |
30209 | 45 | 85 | 20.75 | 67.9 | 83.6 | 0.474 |
30210 | 50 | 90 | 21.75 | 73.3 | 92.1 | 0.529 |
30211 | 55 | 100 | 22.75 | 90.8 | 113.7 | 0.713 |
30212 | 60 | 110 | 23.75 | 103.3 | 130 | 0.923 |
30213 | 65 | 120 | 24.75 | 120.6 | 152.6 | 1.58 |
30214 | 70 | 125 | 26.25 | 132.3 | 173.6 | 1.29 |
30215 | 75 | 130 | 27.25 | 138.4 | 185.4 | 1.4 |
30216 | 80 | 140 | 28.25 | 160.4 | 212.8 | 1.56 |
30217 | 85 | 150 | 30.5 | 177.6 | 236.8 | 2.06 |
30218 | 90 | 160 | 32.5 | 200.1 | 269.6 | 2.54 |
30219 | 95 | 170 | 34.5 | 226.6 | 309 | 3.04 |
30220 | 100 | 180 | 37 | 253.9 | 350.3 | 3.72 |
30221 | 105 | 190 | 39 | 285.3 | 398.6 | 4.38 |
30222 | 110 | 200 | 41 | 314.9 | 443.6 | 5.21 |
30224 | 120 | 215 | 43.5 | 337.4 | 483.3 | 6.2 |
30226 | 130 | 230 | 43.75 | 366 | 521.4 | 6.94 |
30228 | 140 | 250 | 45.75 | 409.2 | 584.7 | 8.73 |
30230 | 150 | 270 | 49 | 451.2 | 645.9 | 10.8 |
30306 | 30 | 72 | 20.75 | 59.6 | 60.1 | 0.389 |
30307 | 35 | 80 | 22.75 | 75.3 | 82.6 | 0.515 |
30308 | 40 | 90 | 25.25 | 80.5 | 90.2 | 0.761 |
30309 | 45 | 100 | 27.25 | 113 | 128 | 0.984 |
30310 | 50 | 110 | 29.25 | 145.3 | 189 | 1.26 |
30311 | 55 | 120 | 31.5 | 153.5 | 187.6 | 1.65 |
30312 | 60 | 130 | 33.5 | 171.4 | 210 | 1.96 |
30313 | 65 | 140 | 36 | 193 | 227 | 2.42 |
30314 | 70 | 150 | 38 | 219 | 271.7 | 3.04 |
30315 | 75 | 160 | 40 | 252.8 | 318.8 | 3.71 |
30316 | 80 | 170 | 42.5 | 278.8 | 352.5 | 4.27 |
30317 | 85 | 180 | 44.5 | 304.9 | 388.2 | 4.96 |
30318 | 90 | 190 | 46.5 | 342.1 | 440.9 | 5.8 |
30319 | 95 | 200 | 49.5 | 369 | 477.7 | 6.8 |
30320 | 100 | 215 | 51.5 | 406.4 | 526.4 | 8.22 |
33008 | 40 | 68 | 22 | 60.2 | 79.6 | 0.306 |
33009 | 45 | 75 | 24 | 72.6 | 100.4 | 0.398 |
33010 | 50 | 80 | 24 | 76.8 | 110.9 | 0.433 |
33011 | 55 | 90 | 27 | 94.9 | 144.7 | 0.651 |
33012 | 60 | 95 | 27 | 96.7 | 151.1 | 0.691 |
33013 | 65 | 100 | 27 | 98.1 | 157.7 | 0.732 |
33014 | 70 | 110 | 31 | 134.4 | 220.4 | 1.07 |
33015 | 75 | 115 | 31 | 133.1 | 221.2 | 1.12 |
33016 | 80 | 125 | 36 | 181.9 | 304.3 | 1.63 |
33017 | 85 | 130 | 36 | 180.4 | 305.5 | 1.69 |
33018 | 90 | 140 | 39 | 232.6 | 388.6 | 2.2 |
33019 | 95 | 145 | 39 | 231 | 389.9 | 2.26 |
33020 | 100 | 150 | 39 | 229.5 | 391.2 | 2.33 |
33021 | 105 | 160 | 43 | 257.4 | 437.4 | 2.97 |
33022 | 110 | 170 | 47 | 288.7 | 502.7 | 3.74 |
33024 | 120 | 180 | 48 | 298.2 | 535.1 | 4.07 |
33026 | 130 | 200 | 55 | 400.6 | 727.4 | 6.14 |
33028 | 140 | 210 | 56 | 407 | 755.5 | 6.57 |
33030 | 150 | 225 | 59 | 461.2 | 873.8 | 7.98 |
33108 | 40 | 75 | 26 | 84.7 | 110.3 | 0.496 |
33109 | 45 | 80 | 26 | 87.1 | 117.2 | 0.535 |
33110 | 50 | 85 | 26 | 89.3 | 124.1 | 0.572 |
33111 | 55 | 95 | 30 | 114.5 | 164.8 | 0.483 |
33112 | 60 | 100 | 30 | 117.1 | 173.2 | 0.895 |
33113 | 65 | 110 | 34 | 142.8 | 220.4 | 1.3 |
33114 | 70 | 120 | 37 | 172.1 | 267 | 1.7 |
33115 | 75 | 125 | 37 | 176.1 | 279.6 | 1.78 |
33116 | 80 | 130 | 37 | 179.6 | 292.3 | 1.87 |
33117 | 85 | 140 | 41 | 215.7 | 354.2 | 2.43 |
33118 | 90 | 150 | 45 | 252.1 | 414.7 | 3.13 |
33119 | 95 | 160 | 49 | 298.9 | 498.2 | 3.94 |
33120 | 100 | 165 | 52 | 309.4 | 529.2 | 4.31 |
33121 | 105 | 175 | 56 | 351.8 | 607.8 | 5.29 |
33122 | 110 | 180 | 56 | 373.2 | 639.1 | 5.5 |
33124 | 120 | 200 | 62 | 448.2 | 779.1 | 7.68 |
33207 | 35 | 72 | 28 | 82.6 | 101.7 | 0.515 |
33208 | 40 | 80 | 32 | 105.8 | 135.5 | 0.715 |
33209 | 45 | 85 | 32 | 109.5 | 145.1 | 0.771 |
33210 | 50 | 90 | 32 | 112.9 | 154.6 | 0.825 |
33211 | 55 | 100 | 35 | 35 | 196.7 | 1.15 |
33212 | 60 | 110 | 38 | 38 | 231.4 | 1.51 |
33213 | 65 | 120 | 41 | 41 | 281.6 | 1.99 |
33214 | 70 | 125 | 41 | 41 | 298.3 | 2.1 |
33215 | 75 | 130 | 41 | 41 | 299.7 | 2.17 |
33216 | 80 | 140 | 46 | 46 | 361.8 | 2.83 |
33217 | 85 | 150 | 49 | 49 | 415.7 | 3.52 |
33218 | 90 | 160 | 55 | 55 | 499.7 | 4.55 |
33219 | 95 | 170 | 58 | 58 | 568.4 | 5.48 |
33220 | 100 | 180 | 63 | 63 | 666.2 | 6.71 |
33221 | 105 | 190 | 68 | 68 | 770.5 | 8.12 |
32909 | 45 | 68 | 15 | 32 | 48.4 | 0.18 |
32910 | 50 | 72 | 15 | 36.9 | 56.1 | 0.181 |
32911 | 55 | 80 | 17 | 41.5 | 66.7 | 0.262 |
32912 | 60 | 85 | 17 | 46.1 | 73.1 | 0.279 |
32913 | 65 | 90 | 17 | 45.4 | 73.2 | 0.295 |
32914 | 70 | 100 | 20 | 70.8 | 114.7 | 0.471 |
32915 | 75 | 105 | 20 | 78.2 | 124.7 | 0.49 |
32916 | 80 | 110 | 20 | 79.3 | 129 | 0.514 |
32917 | 85 | 120 | 23 | 96.9 | 164.1 | 0.767 |
32918 | 90 | 125 | 23 | 95.8 | 164.5 | 0.798 |
32919 | 95 | 130 | 23 | 97.1 | 169.8 | 0.931 |
32920 | 100 | 140 | 25 | 126.6 | 218.4 | 1.12 |
32921 | 105 | 145 | 25 | 128 | 255.6 | 1.16 |
32922 | 110 | 150 | 25 | 129.7 | 232.6 | 1.2 |
32924 | 120 | 165 | 29 | 171.9 | 317.3 | 1.78 |
32926 | 130 | 180 | 32 | 206 | 380.6 | 2.34 |
32928 | 140 | 190 | 32 | 207.2 | 392.4 | 2.47 |
32930 | 150 | 210 | 38 | 261 | 510.4 | 3.87 |
32932 | 160 | 220 | 38 | 262.8 | 525.4 | 4.07 |
32934 | 170 | 230 | 38 | 280.1 | 561.5 | 4.33 |
![Magnetic/Excavator Needle/Yanmar Main/Car Water Pump/Split/Plastic Thrust Bearings/Hub Bearing for Wuling/Motorcycle Parts/Bearing Housing/Plastic Pulley 32313](http://img6.grofrom.com/www.gaiximachineshop.com/226f3j00pAvDgbHKEmrz/Magnetic-Excavator-Needle-Yanmar-Main-Car-Water-Pump-Split-Plastic-Thrust-Bearings-Hub-Bearing-for-Wuling-Motorcycle-Parts-Bearing-Housing-Plastic-Pulley-32313.webp)
![Magnetic/Excavator Needle/Yanmar Main/Car Water Pump/Split/Plastic Thrust Bearings/Hub Bearing for Wuling/Motorcycle Parts/Bearing Housing/Plastic Pulley 32313](http://img6.grofrom.com/www.gaiximachineshop.com/226f3j00gACDrsIcEJzp/Magnetic-Excavator-Needle-Yanmar-Main-Car-Water-Pump-Split-Plastic-Thrust-Bearings-Hub-Bearing-for-Wuling-Motorcycle-Parts-Bearing-Housing-Plastic-Pulley-32313.webp)
![Magnetic/Excavator Needle/Yanmar Main/Car Water Pump/Split/Plastic Thrust Bearings/Hub Bearing for Wuling/Motorcycle Parts/Bearing Housing/Plastic Pulley 32313](http://img6.grofrom.com/www.gaiximachineshop.com/226f3j00pJBPgAHFkdrz/Magnetic-Excavator-Needle-Yanmar-Main-Car-Water-Pump-Split-Plastic-Thrust-Bearings-Hub-Bearing-for-Wuling-Motorcycle-Parts-Bearing-Housing-Plastic-Pulley-32313.webp)
![Magnetic/Excavator Needle/Yanmar Main/Car Water Pump/Split/Plastic Thrust Bearings/Hub Bearing for Wuling/Motorcycle Parts/Bearing Housing/Plastic Pulley 32313](http://img6.grofrom.com/www.gaiximachineshop.com/226f3j00DdCPpGIMCmug/Magnetic-Excavator-Needle-Yanmar-Main-Car-Water-Pump-Split-Plastic-Thrust-Bearings-Hub-Bearing-for-Wuling-Motorcycle-Parts-Bearing-Housing-Plastic-Pulley-32313.webp)
![Magnetic/Excavator Needle/Yanmar Main/Car Water Pump/Split/Plastic Thrust Bearings/Hub Bearing for Wuling/Motorcycle Parts/Bearing Housing/Plastic Pulley 32313](http://img6.grofrom.com/www.gaiximachineshop.com/226f3j00PJBDrHIdfAgu/Magnetic-Excavator-Needle-Yanmar-Main-Car-Water-Pump-Split-Plastic-Thrust-Bearings-Hub-Bearing-for-Wuling-Motorcycle-Parts-Bearing-Housing-Plastic-Pulley-32313.webp)
We have a wealth of technical.All producing processes are finished in our manufactory. As an ISO9001:2000 certified manufacturer,we will solve various problems in application and use of our bearings.
Our company is an authorized distributor of FAG, INA, TIMKEN and other world brand bearings.Our company has the right to self-export bearings and launches its own brand RTB.
Our bearing had been exported to more than twenty countries worldwide and are warmly welcomed.
We're looking forward to your order.
![Magnetic/Excavator Needle/Yanmar Main/Car Water Pump/Split/Plastic Thrust Bearings/Hub Bearing for Wuling/Motorcycle Parts/Bearing Housing/Plastic Pulley 32313](http://img6.grofrom.com/www.gaiximachineshop.com/226f3j00IJBPpkHsfAzu/Magnetic-Excavator-Needle-Yanmar-Main-Car-Water-Pump-Split-Plastic-Thrust-Bearings-Hub-Bearing-for-Wuling-Motorcycle-Parts-Bearing-Housing-Plastic-Pulley-32313.webp)
![Magnetic/Excavator Needle/Yanmar Main/Car Water Pump/Split/Plastic Thrust Bearings/Hub Bearing for Wuling/Motorcycle Parts/Bearing Housing/Plastic Pulley 32313](http://img6.grofrom.com/www.gaiximachineshop.com/226f3j00IACPgSLECmrp/Magnetic-Excavator-Needle-Yanmar-Main-Car-Water-Pump-Split-Plastic-Thrust-Bearings-Hub-Bearing-for-Wuling-Motorcycle-Parts-Bearing-Housing-Plastic-Pulley-32313.webp)
1.Is the company a production factory or a trading company?
TIANJIN REET BEARING CO.,LTD is a manufacturing enterprise focusing on bearings and integrating research, production and sales.
2.How many the MOQ of your company?
Depending on the size of the bearing, the MOQ is variable, if you are interested, you can contact me for a quote.
3.Does the company accept OEM or customized bearings?
In addition to standard products, we also supply non-standard and modified standard products for special application. Meanwhile, we provide OEM service.
4.Can the company provide free samples?
We can provide samples for free. You only need to provide shipping.
5.What are the company's delivery terms?
We can accept EXW,FOB,CFR,CIF,etc. You can choose the one which is the most convenient cost effective for you.
