Glass Fiber Fiberglass 30kn/M Geogrid for Road Bed Railway

Get high-quality Glass Fiber Fiberglass 30kn/M Geogrid for Road Bed Railway from our factory. Durable and reliable solution for your construction needs.
Request a Quote

PRODUCTS DETAILS

Basic Info.

Model NO.
Fiberglass Geogrid
Application
Retaining Wall, Steep Slop, Dam, Road Base
Viscose
Without Viscose
Function
Anti-slip, Reinforcement
Classification
Fiberglass Geogrid
Material
Fiberglass
Size
50X50kn/M
Raw Material
Glass Fiber
Certificate
CE/ISO9001/BV
Width
1-6m
Length
50m/100m/Customer Requirement
Performance
High Tensile Strength Longitudinal and Transverse
Market
Europe, Africa, Asia, Middle East etc.
Samples
Free Samples
Model
30kn/60kn/80kn/100kn/150kn/200kn
Transport Package
Black PE Film or Woven Bags for Outside Packag
Specification
12.7*12.7 / 25.4*25.4 /40*40
Trademark
zhongloo
Origin
China
HS Code
70191900
Production Capacity
50000m2/Day

Packaging & Delivery

Package Size
50.00cm * 50.00cm * 10.00cm
Package Gross Weight
1.000kg

Product Description

Glass Fiber Fiberglass 30KN/M Geogrid for Road Bed Railway

Introduction:
Glass Fiber Geogrid is composed of a reticular structural material made of glass fiber filament with modified bitumen coating. It withstands high and low temperatures and can resist corrosion. FiberGlass geogrid is a stress relief asphalt reinforcement grid developed specifically for ashpalt overlays. Fiber Glass geogrid can not only decrease the cost of construction but also longer the service life of the pavement and road.
Glass Fiber Geogrid in a pavement system can distribute traffic loading of vehicle and prevent reflective cracking due to temperature difference to extend service life of pavement.


Glass Fiber Fiberglass 30kn/M Geogrid for Road Bed Railway
Features:

The product has the characteristics of high strength, low elongation, high temperature resistance, high modulus, light weight, good toughness, corrosion resistance, long life and so on. In engineering fields such as slope protection, road and bridge pavement enhancement treatment, it can strengthen and reinforce the pavement, prevent pavement rutting fatigue cracks, hot-cold expansion cracks and reflection cracks below, and can disperse the bearing stress of the pavement, prolong the service life of the pavement, high Low tensile strength, low elongation, no long-term creep, good physical and chemical stability, good thermal stability, anti-fatigue cracking, high temperature rutting resistance, low temperature shrinkage crack resistance, delay and reduce reflection cracks.


Glass Fiber Fiberglass 30kn/M Geogrid for Road Bed Railway
Glass Fiber Fiberglass 30kn/M Geogrid for Road Bed Railway



Data Sheet
SPECIFICATION  EGA3030 EGA5050 EGA8080 EGA100100 EGA120120 EGA150150 EGA200200
Ultimate Strength
(KN/M)
MD ≥30 ≥50 ≥80 ≥100 ≥120 ≥150 ≥200
CMD ≥30 ≥50 ≥80 ≥100 ≥120 ≥150 ≥200
elongation(%) ≤4 ≤4 ≤4 ≤4 ≤4 ≤4 ≤4
Grid Size, mm 12.5-40.00
Width 6 Meter Maximum

Application:

1. The old asphalt concrete pavement is reinforced to strengthen the asphalt surface layer to prevent diseases.

2. The cement concrete pavement is converted into a composite pavement to suppress reflection cracks caused by plate shrinkage.

3. Road extension and improvement project to prevent cracks caused by the junction of new and old and uneven settlement.

4. Reinforcement treatment of soft soil foundation is conducive to the consolidation of soft soil water separation, effectively inhibits settlement, uniform stress distribution, and enhances the overall strength of the roadbed.

5. The semi-rigid base of the newly built road produces shrinkage cracks, and the reinforcement is reinforced to prevent the pavement cracks caused by the reflection of the base cracks.


Glass Fiber Fiberglass 30kn/M Geogrid for Road Bed Railway
Glass Fiber Fiberglass 30kn/M Geogrid for Road Bed Railway

Glass Fiber Fiberglass 30kn/M Geogrid for Road Bed Railway
