Basic Info.
Model NO.
4x4mm 5x5mm
Weave Type
Twill Woven
Fiberglass Type
C-Glass
Alkali Content
Medium
Transport Package
Woven Bag or Carton or Pallet
Specification
45g-300g
Origin
China
HS Code
7019902190
Production Capacity
1000000m2/Month
Product Description
ALKALINE RESISTANT FIBERGLASS MESH
Fiberglass alkaline-resistance mesh fabric is on the basis of C-glass or E-glass woven fabric,then handle formed by alkali-resistant coating. the product has high strength,good paste,obedient,excellent positioning,is widely used in wall enhanced external wall insulation,roofing,etc.also can be applied to cement,plastics,asphalt,marble,mosaic wall materials enhancements, It is an ideal engineering material in construction.
Fiberglass mesh is woven by fiberglass yarn as its basis mesh, and then coated by alkaline resistant latex. It has fine alkaline-resistant, high strength, etc. As an ideal engineering material in construction, it is mainly used to reinforce cement, stone, wall materials, roofing, and gypsum and so on.
We can produce any size mesh according to requirements of customer like different mesh size and weight per square meter.
We can supply special mesh as following:
(1)High strength mesh,
(2) Fire proof mesh.
(3)Strong and flexible mesh
We can supply specifications from 30g/m2 to 500g/m2 for mesh.
Main size: 5mm x 5mm or 4mm x 4mm,10x10mm,2.8x2.8mm 75 g/m2, 90 g/m2, 125 g/m2,145 g/m2, 160 g/m2. And so on
Fiberglass mesh is woven by fiberglass yarn as its basis mesh, and then coated by alkaline resistant latex. It has fine alkaline-resistant, high strength, etc. As an ideal engineering material in construction, it is mainly used to reinforce cement, stone, wall materials, roofing, and gypsum and so on.
We can produce any size mesh according to requirements of customer like different mesh size and weight per square meter.
We can supply special mesh as following:
(1)High strength mesh,
(2) Fire proof mesh.
(3)Strong and flexible mesh
We can supply specifications from 30g/m2 to 500g/m2 for mesh.
Main size: 5mm x 5mm or 4mm x 4mm,10x10mm,2.8x2.8mm 75 g/m2, 90 g/m2, 125 g/m2,145 g/m2, 160 g/m2. And so on
Fiberglass alkaline-resistance mesh fabric is on the basis of C-glass or E-glass woven fabric,then handle formed by alkali-resistant coating. the product has high strength,good paste,obedient,excellent positioning,is widely used in wall enhanced external wall insulation,roofing,etc.also can be applied to cement,plastics,asphalt,marble,mosaic wall materials enhancements, It is an ideal engineering material in construction.
Fiberglass mesh is woven by fiberglass yarn as its basis mesh, and then coated by alkaline resistant latex. It has fine alkaline-resistant, high strength, etc. As an ideal engineering material in construction, it is mainly used to reinforce cement, stone, wall materials, roofing, and gypsum and so on.
We can produce any size mesh according to requirements of customer like different mesh size and weight per square meter.
We can supply special mesh as following:
(1)High strength mesh,
(2) Fire proof mesh.
(3)Strong and flexible mesh
We can supply specifications from 30g/m2 to 500g/m2 for mesh.
Main size: 5mm x 5mm or 4mm x 4mm,10x10mm,2.8x2.8mm 75 g/m2, 90 g/m2, 125 g/m2,145 g/m2, 160 g/m2. And so on
| Art.No. | Mesh/Size(MM) | Specification | Weight/m2 | Diameter(mm) | Qty./Ctn | Size of carton(MM) | Quantity/20Ft container Abt | Quantity/40Ft container Abt | |
| GY5x5/6x6-60 | 5x5/4x4 | 1MX50M | 60g | 135 | 4Rolls/carton | 1020x270x270 | 67600M2 | 160800M2 | |
| GY5x5/6x6-70 | 5x5/4x4 | 1MX50M | 70g | 140 | 4Rolls/carton | 1020x280x280 | 65200M2 | 155400M2 | |
| GY5x5/6x6-90 | 5x5/4x4 | 1MX50M | 90g | 148 | 4Rolls/carton | 1020x300x300 | 61000M2 | 145400M2 | |
| GY5x5/6x6-100 | 5x5/4x4 | 1MX50M | 100g | 150 | 4Rolls/carton | 1020x305x305 | 59000M2 | 140600M2 | |
| GY5x5/6x6-110 | 5x5/4x4 | 1MX50M | 155g | 155 | 4Rolls/carton | 1020x310x310 | 55400M2 | 132000M2 | |
| GY5x5/6x6-120 | 5x5/4x4 | 1MX50M | 160g | 160 | 4Rolls/carton | 1020x320x320 | 52200M2 | 124200M2 | |
| GY5X5/6X6-125 | 5x5/4x4 | 1MX50M | 125g | 165 | 4Rolls/carton | 1020x330x330 | 49000M2 | 117000M2 | |
| GY5X5/6X6-130 | 5x5/4x4 | 1MX50M | 130g | 166 | 4Rolls/carton | 1020X335X335 | 49000M2 | 117000M2 | |
| GY5X5/6X6-145 | 5x5/4x4 | 1MX50M | 145g | 168 | 2Rolls/carton | 1020X170X340 | 45800M2 | 113000M2 | |
| GY5X5/6X6-150 | 5x5/4x4 | 1MX50M | 150g | 170 | 2Rolls/carton | 1020X170X340 | 45800M2 | 113000M2 | |
| GY5X5/6X6-160 | 5x5/4x4 | 1MX50M | 160g | 173 | 2Rolls/carton | 1020X175X345 | 43500M2 | 112400M2 | |
| GY5X5/6X6-165 | 5x5/4x4 | 1MX50M | 165g | 175 | 2Rolls/carton | 1020X175X345 | 43500M2 | 112400M2 | |
| GY2.5x2.5-70 | 10x10 | 1MX50M | 70g | 175 | 2Rolls/carton | 1020x175x350 | 42000M2 | 105500M2 | |
| GY2.5x2.5-90 | 10x10 | 1MX50M | 90g | 180 | 2Rolls/carton | 1020x180x360 | 40100M2 | 100700M2 | |
| GY2.5x2.5-100 | 10x10 | 1MX50M | 100g | 185 | 2Rolls/carton | 1020x185x370 | 37800M2 | 95400M2 | |
| GY2.5x2.5-125 | 10x10 | 1MX50M | 125g | 210 | 2Rolls/carton | 1020X210X420 | 29500M2 | 73800M2 | |
| GY2.5x2.5-130 | 10x10 | 1MX50M | 130g | 215 | 2Rolls/carton | 1020x220x435 | 27100M2 | 67900M2 | |
| GY2.5x2.5-150 | 10x10 | 1MX50M | 150g | 220 | 2Rolls/carton | 1020X220X440 | 26700M2 | 67200M2 | |
| GY8X8-53 | 3.2X3.2 | 1MX100M | 53g | 170 | 2Rolls/carton | 1020x170x340 | 46000M2 | 113000M2 | |
| GY9X9-60 | 2.8X2.8 | 1MX100M | 60g | 170 | 2Rolls/carton | 1020x170x340 | 46000M2 | 113000M2 | |
ALKALINE RESISTANT FIBERGLASS MESH
Fiberglass mesh is woven by fiberglass yarn as its basis mesh, and then coated by alkaline resistant latex. It has fine alkaline-resistant, high strength, etc. As an ideal engineering material in construction, it is mainly used to reinforce cement, stone, wall materials, roofing, and gypsum and so on.
We can produce any size mesh according to requirements of customer like different mesh size and weight per square meter.
We can supply special mesh as following:
(1)High strength mesh,
(2) Fire proof mesh.
(3)Strong and flexible mesh
We can supply specifications from 30g/m2 to 500g/m2 for mesh.
Main size: 5mm x 5mm or 4mm x 4mm,10x10mm,2.8x2.8mm 75 g/m2, 90 g/m2, 125 g/m2,145 g/m2, 160 g/m2. And so on
