Air Jet Loom740 Price Medical Gauze Weaving Machine Air Jet Loom High Efficiency Production Line Fair Price Jlh740 Zax



Product Parameters

Qingdao Jin Lihua Textile Machinery Co.

Item		Specification	Remark
Reed width	Reed width(cm)	110  150  170
	Useful reed width	Reduce 0-60cm (110-170cm)
Fabric	Material & weave	Gauze fabric
Power	Main power	2.2kw
Speed	Motor-belt pulley	RPM  500
Weft insertion	Weft selection	Single color
	Feeder	Vibration model
		Without WBS
		1
Shedding	Shedding method	Crank plain shedding
	Heald frame	2   4 Brand Jinlihua China
Let off device	Mechanical type Electronic type	Single beam
	Flange diameter	Ø800     Ø914   Ø1000
Take up device	Take up	Mechanical take-up(MTU)
	Max cloth roll diameter	Ø600mm(crank) Ø1200mm(jumb batching motion)
	Weft density	Take 40s cotton yarn for example
		4-10picks/inch
Beating	Roller beating system	Four-bar beating -up motion (below 230cm)
Selvage		Leno gear selvage
edge		Tuck-in device  or  leno selvage
Cutter		Mechanical cutter
Lubrication		Manual oil supply
Stop motion	Warp stop	Electric 2-row contact bar system
Control system	Sanhe brand Made-in-China
Accessory		Heald wire    s.s	3000pcs
		Warp beam	1:1.5
		Cloth roller	1:1.5
		Reed  energy-saving type	1:1
		Dropper  close or  open	3000pcs

    *We are very willing to provide you with the technical information on the model together with the catalog and price list.

   JINLIHUA 's textile machinery business will constantly explores the future of the textile industry by providing products with the high productivity and quality while also implementing active environmental policies including energy conservation and reduction of waste pollution, and providing detailed, attentive service.

 Qingdao Jin Lihua Textile Machinery Co.

  "JLH740" is a high performance weaving air jet loom for new era.we provided Newly upgraded electric components and Integrated high technology to support weaving,  JLH740 combines Mechatronics with high technology, which realizes the stable weaving of high quality textile.

Product advantages:
1) It can operate without air compressor, and there is no need to make an air tunnel. This machine saves a lot of power.

2)Using non-sizing yarn to produce the fabric by this model machine.Saving the sizing cost also.

3)the production is much higher than shuttle loom and rapier loom.

4)Exclusive technical and professional team to ensure supply and quality.

5)Easy to operate,and low maintainess charge.

  The "JLH740" upgrades the high-speed ability of the predecessors. JLH740 has the advantages of simple structure, high reliability, easy long-term storage, can be quickly used. It is an advanced air jet loom that saves resources, energy, and manpower.

  The "JLH740" is a high performance weaving air jet loom for new era.we provided Newly upgraded electric components and Integrated high technology to support weaving, the JLH740 combines mechatronics with high technology, which realizes the stable weaving of high quality textile.

Qingdao Jin Lihua Textile Machinery Co.

 ^*We sincerely hope to establish good business relationship with customers home and abroad, to cooperate frankly on the basis of mutual benefit, reliable quality products and favorable prices.

(1) Q: Are you a manufacturer or agency?
A: We are a professional manufacturer holding our own International Trade Department, for that can better understand customer's needs and offer a reasonable price.

(2) Q: Are you available for on-the-spot invitation?
A: We do welcome our new and old friends come here to have a visitation. Besides, we would send you our exposition and relative information to promote a face-to-face meeting if you'd like to.

(3) Q: Is the price offered changeable?
A: We offer reasonable price for every client, and the price is changeable according to purchasing amount.

(4) Q: How about the quality?
A:The main subassembly and raw materials are all supplied by large companies. Key parts are research and developed by our own staff. Professional assembly line work and strict quality test system can ensure your high quality requirement.

(5) Q: How's the after-sale service?
A: We offer engineers available to service overseas under merchandiser's supervision and translation.

(6) What about the delivery time?
A: General delivery time is 20 days or so for one container after we recieved your downpayment.If the order is less and we have stocks also,the delivery time is 10 days or so.If our factory is busy,then we will negotiate the time according to our production plan.
^*If you have any suggestions on how this website and our services could be improved to serve you better, please do not hesitate to let us know.
